Laser Cutting Machine G3015
Features:
- Fiber laser cutting
- Cutting sheet metal thickness 0.5-16mm of carbon steel, 0.5-8mm of stainless steel
- Also able to cut aluminium alloy plate, galvanized plate, electrolytic plate, silicon steel, galvanized steel plate, PVC, MDF, acrylic, ABS, wood and other non-metallic materials
- CNC control
- Head with water chilling to control the heat
- Head with sensor to assure nozzle height accuracy
- Proximity switches for safety of movement
- Automatic lubrication for ballscrews and pinion-rack system
Technical Specifications
|
Model |
G3015 |
|
Working area |
3000×1500 mm |
|
X travel |
3000 mm |
|
Y travel |
1500 mm |
|
Z travel |
0-120 mm |
|
Laser generator type |
fiber laser type |
|
Laser power |
2000W |
|
Positioning accuracy |
±0.03mm/m |
|
Repeatability |
±0.02mm |
|
Cutting accuracy |
≤0.01mm |
|
Idle rapid speed, max |
80-120m/min |
|
Cutting speed, max |
45-60m/min |
 |
 |
 |
 |
